Two-way radios are often used in challenging environments such as outdoor sites, industrial areas, and other noisy settings where machinery, wind, and traffic sounds interfere with clear voice communication. In such conditions, microphones must effectively reduce background noise and focus on the speaker’s voice. This typically requires a unidirectional design and a good signal-to-noise ratio to ensure voice clarity.
Furthermore, improper microphone sensitivity or limited frequency response can result in muffled sound or loss of voice details, especially when the speaker is not close to the microphone. It is crucial to balance sensitivity to prevent distortion from loud sounds while maintaining sufficient pickup. A frequency response that covers key human voice ranges (around 100Hz to 10kHz) is important to reproduce natural, clear audio.
Microphones also need to handle sudden loud noises without distortion; therefore, a high maximum sound pressure level (SPL), typically over 100dB, is necessary to maintain stability in emergencies or noisy bursts. Mechanical factors are also important since limited internal space demands precise microphone sizing and compatible pin configurations for secure soldering. This helps prevent poor contact caused by vibrations and ensures long-term reliability.
Offering standard sizes such as 6mm and 9.7mm for two-way radios, along with robust packaging and standardized pin layouts, supports easier integration and durability.
ECM-B6027UP-47: A Versatile Electret Microphone Suitable for Multiple Applications
| Parameter | Specification |
|---|---|
| Talla | 6 × 2,7 mm |
| Directionality | Unidireccional |
| Sensibilidad | -47dB ± 2 |
| Impedancia | 680Ω |
| Signal-to-Noise Ratio | 52dB |
| Maximum SPL | 100dB |
| Respuesta de frecuencia | 100Hz ~ 10kHz |
| Tensión de funcionamiento | 1.5V DC |
Though originally designed for musical instrument applications, the ECM-B6027UP-47 electret microphone offers features that make it well-suited for two-way radio use. Its unidirectional design helps precisely capture the speaker’s voice while effectively reducing ambient noise common in noisy environments.
With a sensitivity of -47dB, it balances audio pickup and distortion prevention to maintain clear communication without clipping during typical speech volumes. The frequency response from 100Hz to 10kHz covers essential voice frequencies, ensuring natural and detailed sound reproduction.
Compact at 6×2.7mm, this microphone easily fits into most two-way radio handset designs, and its pin-type connector facilitates reliable PCB soldering for efficient manufacturing. Although its signal-to-noise ratio of 52dB is moderate, it meets common requirements for two-way radios, providing stable and dependable performance in practical applications.
How We Help Clients Achieve High-Quality Two-Way Radio Microphone Solutions
Our company offers a diverse range of electret microphones with options to customize sensitivity, pin layouts, and packaging to satisfy various design needs. Automated production lines and advanced sealing technology guarantee consistent quality and reduce defect rates, helping clients maintain product reliability.
We provide expert technical support, assisting with microphone selection, mechanical integration, and electrical tuning to speed up development cycles and validation. Additionally, we offer rapid prototyping and small-batch sample services to accommodate different project phases from design verification to full-scale manufacturing.
Selecting the right microphone is essential for ensuring clear and reliable voice communication in two-way radios. The ECM-B6027UP-47’s unidirectional pattern, appropriate sensitivity, and compact size make it a practical and effective choice.
If you are looking for dependable electret microphone components for two-way radio applications, visit our product page or contact us for personalized recommendations and customization options that enhance voice clarity and communication quality.
